 | Continuous |
Class managing sequence recording of undefined size.
Inheritance HierarchySystemObject
LynceeTec.API.SequenceConfigurationEventsManager
LynceeTec.API.SequenceBaseSequenceManager
LynceeTec.API.SequenceBaseAcquirer
LynceeTec.API.SequenceLiveAcquirer
LynceeTec.API.SequenceContinuousSequenceRecorder
LynceeTec.API.SequenceConfigurationEventsManager
LynceeTec.API.SequenceBaseSequenceManager
LynceeTec.API.SequenceBaseAcquirer
LynceeTec.API.SequenceLiveAcquirer
LynceeTec.API.SequenceContinuousSequenceRecorder
Namespace: LynceeTec.API.Sequence
Assembly: LynceeTec.API.Sequence (in LynceeTec.API.Sequence.dll) Version: 10.2.3317.0 , built 2025-03-17 14:55:36 UTC
SyntaxThe ContinuousSequenceRecorder type exposes the following members.
Constructors| Name | Description | |
|---|---|---|
 | ContinuousSequenceRecorder | Initializes a new instance of the ContinuousSequenceRecorder class |
Properties| Name | Description | |
|---|---|---|
 | AcquisitionFps |
Gets or sets the acquisition frame rate.
(Inherited from LiveAcquirer) |
| ConfigManager |
Gets the current ConfigManager in use.
(Inherited from BaseSequenceManager) |
| Configuration |
Gets the current configuration used for hologram reconstruction.
(Inherited from BaseSequenceManager) |
| CurrentState |
Gets the current state of the sequence manager.
(Inherited from BaseSequenceManager) |
| EffectiveAcquisitionFps |
Gets the effective acquisition frame rate.
(Inherited from LiveAcquirer) |
| EffectiveReconstructionFps |
Gets the effective reconstruction frame rate.
(Inherited from LiveAcquirer) |
| NumberOfRecords |
Gets the current total number of records.
(Inherited from BaseSequenceManager) |
| ReconstructionFps |
Gets or sets the reconstruction frame rate.
(Inherited from LiveAcquirer) |
| ReconstructionWindowHalfSize |
Defines how many reconstructions must be processed around the selected index.
If GetReconstruction(ReconstructionResults, Int32, Boolean) is called for index i, outputs in range
[i - ReconstructionWindowHalfSize, i + ReconstructionWindowHalfSize]
are reconstructed to optimize the process and anticipate the call to future indices.
(Inherited from BaseSequenceManager) |
| TemporalAveragingFramesNumber |
Gets or sets the number of frames to average during reconstruction process.
(Inherited from BaseSequenceManager) |
| UseReconstruction |
Gets or sets a value indicating whether the reconstruction is enabled.
(Inherited from LiveAcquirer) |
| UseReferenceHologramSaving |
Gets or sets the option saving the reference hologram(s) in the first hologram metadata of the acquired sequence.
(Inherited from BaseSequenceManager) |
Methods| Name | Description | |
|---|---|---|
| AccessHologram |
Accesses the hologram object directly in the current buffer.
(Inherited from BaseSequenceManager) |
| CancelSaving |
Cancels the saving of a sequence.
(Inherited from BaseSequenceManager) |
| CastSequence |
Casts an existing sequence into the current buffer.
(Inherited from BaseSequenceManager) |
| ComputeAndApplyFittingToConfiguration |
Compute fitting on the phase result of the next acquisition using configuration parameters.
(Inherited from LiveAcquirer) |
| ComputeAndApplyFittingToConfiguration(Int32, Boolean) |
Compute fitting on specified phase result using configuration parameters.
(Inherited from BaseSequenceManager) |
| DeregisterConfigurationMemberModifiedEvent |
Deregister a function registered to the specified member.
(Inherited from ConfigurationEventsManager) |
| DeregisterConfigurationModifiedEvent |
Deregister a registered function.
(Inherited from ConfigurationEventsManager) |
| Dispose | (Inherited from ConfigurationEventsManager) |
| ExtractSequence |
Extract the current sequence buffer and resets the data.
(Inherited from BaseSequenceManager) |
| GetHologramCopy |
Gets a copy of the defined hologram in the current buffer.
(Inherited from BaseSequenceManager) |
| GetNextAcquisition |
Get the next acquisition.
(Inherited from LiveAcquirer) |
| GetNextReconstruction |
Get the reconstruction results of the next acquired data.
(Inherited from LiveAcquirer) |
| GetReconstruction |
Gets the reconstruction results of a record in the current buffer.
(Inherited from BaseSequenceManager) |
| IsInState |
Determines if the state machine is in the supplied state.
(Inherited from BaseSequenceManager) |
| RegisterConfigurationMemberModifiedEvent |
Register a function that will be executed when the specified member is modified.
(Inherited from ConfigurationEventsManager) |
| RegisterConfigurationModifiedEvent |
Register a function that will be executed when any configuration member is modified.
(Inherited from ConfigurationEventsManager) |
| Reset |
Resets recorded buffer.
(Inherited from BaseSequenceManager) |
| SaveBigTiffSequence |
Saves the sequence into a BigTiff (.btf) format.
(Inherited from BaseSequenceManager) |
| SaveKoalaSequence |
Saves the sequence in a Koala compatible format.
(Inherited from BaseSequenceManager) |
| StartAcquiring |
Starts the live acquisition.
(Inherited from LiveAcquirer) |
| StartRecording | Starts recording the continuous acquisition. |
| StopAcquiring |
Stops the live acquisition.
(Inherited from LiveAcquirer) |
| StopRecording | Stops recording the acquisition. |
Events| Name | Description | |
|---|---|---|
 | ActiveConfigurationChanged | (Inherited from BaseSequenceManager) |
| LastReconstructionComputed |
Sends results for each new reconstruction. If UseReconstruction is disabled, the hologram only is send at acquisition frame rate.
(Inherited from LiveAcquirer) |
| StateMachineStateChanged |
Occurs when the state machine state changes
(Inherited from BaseSequenceManager) |
RemarksSome calls to the class elements can only be performed when CurrentState has some defined values. The following scheme describes the allowed actions.
Thread SafetyStatic members of this type are safe for multi-threaded operations. Instance members of this type are safe for multi-threaded operations.
